About
Every connector type in the kit, assembled and asserted. Wall to wall, wall to inner corner and wall to outer corner on the wall-end port; slab to slab on the floor-edge port; stair to landing, ramp foot to floor deck, catwalk to catwalk corner and stair head to upper deck on the deck-edge port; parapet to parapet and column foot to foundation pedestal on the run-end port. The generator checks all ten pairs in world coordinates, so drift in any module fails the build rather than the review.
Use with an AI agent
Copy this prompt into your AI chat, then describe what you want to build with the asset.
Use the “Greybox connector cases (Modular Greybox Architecture Kit)” asset in my project. Model: https://cdn.3dassets.dev/assets/8272/v1/model.glb Asset page: https://3dassets.dev/assets/modular-greybox-architecture-kit-connector-cases-26ff8c12 Description: Composed example for Modular Greybox Architecture Kit. - Dimensions (X × Y × Z): 27 × 4.284 × 26.264 metres - Triangles: 4.3k - Animations: none - Licence: CC0 1.0 Universal (https://creativecommons.org/publicdomain/zero/1.0/) - Loading: Three.js GLTFLoader; no additional decoders required.
Also available as JSON, Markdown, or via the MCP server.
Import manually
Choose your framework, then copy the code into your project to load the asset.
import { GLTFLoader } from 'three/addons/loaders/GLTFLoader.js'
const loader = new GLTFLoader()
loader.load('https://cdn.3dassets.dev/assets/8272/v1/model.glb', (gltf) => {
scene.add(gltf.scene)
})Greybox connector cases (Modular Greybox Architecture Kit)
Composed example for Modular Greybox Architecture Kit.
