A 4 m floor tile with a 1.2 m rebated trapdoor cut and a recessed seating ledge, ready for a hatch lid or a ladder drop. Dimensions 4.00 x 0.20 x 4.00 m (X x Y x Z). Origin at the cell centre; the cut is centred on the origin. Metres, +Y up, +Z front, ground contact at y=0. The steel ledge sits 0.04 m below the deck so a 1.2 m hatch lid finishes flush. Connectors: floor-west (floor-edge), floor-east (floor-edge), floor-south (floor-edge), floor-north (floor-edge), deck-west (deck-edge), deck-east (deck-edge), deck-south (deck-edge), deck-north (deck-edge). Neutral greybox palette for prototyping before art exists. Static geometry; no skinned rig, collision or navigation data.
Use with an AI agent
Copy this prompt into your AI chat, then describe what you want to build with the asset.
Use the “Greybox floor tile with trapdoor cut (Modular Greybox Architecture Kit)” asset in my project. Model: https://cdn.3dassets.dev/assets/8190/v1/model.glb Asset page: https://3dassets.dev/assets/modular-greybox-architecture-kit-floor-trapdoor-cut-d1d87661 Description: A 4 m floor tile with a 1.2 m rebated trapdoor cut and a recessed seating ledge, ready for a hatch lid or a ladder drop. - Dimensions (X × Y × Z): 4 × 0.2 × 4 metres - Triangles: 504 - Animations: none - Licence: CC0 1.0 Universal (https://creativecommons.org/publicdomain/zero/1.0/) - Loading: Three.js GLTFLoader; no additional decoders required.
Also available as JSON, Markdown, or via the MCP server.
Import manually
Choose your framework, then copy the code into your project to load the asset.
import { GLTFLoader } from 'three/addons/loaders/GLTFLoader.js'
const loader = new GLTFLoader()
loader.load('https://cdn.3dassets.dev/assets/8190/v1/model.glb', (gltf) => {
scene.add(gltf.scene)
})Greybox floor tile with trapdoor cut (Modular Greybox Architecture Kit)
A 4 m floor tile with a 1.2 m rebated trapdoor cut and a recessed seating ledge, ready for a hatch lid or a ladder drop.
