About
A tipping point over an ore pass raise: a concrete collar around a 2 m square opening, heavy grizzly bars, a kickboard kerb, a side chute and a control stand. Dimensions 3.40 by 2.46 by 3.88 m (X by Y by Z), metre units, +Y up, +Z forward, resting on y=0. Static geometry; no rig, collision or navigation data.
Use with an AI agent
Copy this prompt into your AI chat, then describe what you want to build with the asset.
Use the “Ore pass raise collar (Underground Mine and Shaft Works)” asset in my project. Model: https://cdn.3dassets.dev/assets/16350/v1/model.glb Asset page: https://3dassets.dev/assets/underground-mine-and-shaft-works-ore-pass-raise-collar-04f58864 Description: A tipping point over an ore pass raise: a concrete collar around a 2 m square opening, heavy grizzly bars, a kickboard kerb, a side chute and a control stand. - Dimensions (X × Y × Z): 3.4 × 2.465 × 3.88 metres - Triangles: 288 - Animations: none - Licence: CC0 1.0 Universal (https://creativecommons.org/publicdomain/zero/1.0/) - Loading: Three.js GLTFLoader; no additional decoders required.
Also available as JSON, Markdown, or via the MCP server.
Import manually
Choose your framework, then copy the code into your project to load the asset.
import { GLTFLoader } from 'three/addons/loaders/GLTFLoader.js'
const loader = new GLTFLoader()
loader.load('https://cdn.3dassets.dev/assets/16350/v1/model.glb', (gltf) => {
scene.add(gltf.scene)
})Ore pass raise collar (Underground Mine and Shaft Works)
A tipping point over an ore pass raise: a concrete collar around a 2 m square opening, heavy grizzly bars, a kickboard kerb, a side chute and a control stand.
