An 11.5 m deployed photovoltaic wing: a rotating base canister on a named gimbal node, a lattice mast and two 9.2 by 3.3 m blankets with cell strips, edge battens and a tensioning bar. Bounding size 11.40 x 1.51 x 7.10 m (X x Y x Z). Metre units, +Y up, +Z forward, lowest geometry resting on y=0. Movable parts are separate named nodes with local pivots: array-gimbal. Assembly ports: truss-port (truss). Truss centreline sits 0.70 m above y=0. The blanket assembly rotates with the array-gimbal node. Static geometry; no rig, collision or navigation data.
Use with an AI agent
Copy this prompt into your AI chat, then describe what you want to build with the asset.
Use the “Deployed solar array wing (Orbital Station and Docking Bays)” asset in my project. Model: https://cdn.3dassets.dev/assets/11283/v1/model.glb Asset page: https://3dassets.dev/assets/orbital-station-and-docking-bays-solar-array-wing-depl-7b69ef49 Description: An 11.5 m deployed photovoltaic wing: a rotating base canister on a named gimbal node, a lattice mast and two 9.2 by 3.3 m blankets with cell strips, edge battens and a tensioning bar. - Dimensions (X × Y × Z): 11.4 × 1.51 × 7.1 metres - Triangles: 1,540 - Animations: none - Licence: CC0 1.0 Universal (https://creativecommons.org/publicdomain/zero/1.0/) - Loading: Three.js GLTFLoader; no additional decoders required.
Also available as JSON, Markdown, or via the MCP server.
Import manually
Choose your framework, then copy the code into your project to load the asset.
import { GLTFLoader } from 'three/addons/loaders/GLTFLoader.js'
const loader = new GLTFLoader()
loader.load('https://cdn.3dassets.dev/assets/11283/v1/model.glb', (gltf) => {
scene.add(gltf.scene)
})Deployed solar array wing (Orbital Station and Docking Bays)
An 11.5 m deployed photovoltaic wing: a rotating base canister on a named gimbal node, a lattice mast and two 9.2 by 3.3 m blankets with cell strips, edge battens and a tensioning bar.
