A 3.2 m base plate carries two painted stools with bearing blocks and a through axle at 0.94 m. The deck is 2.5 m by 1.9 m with seven grip ribs, edge channels and amber bands, over two amber floor kerbs and a control box with a lamp. Overall size 3.2 x 1.1 x 2.2 m in metres, +Y up, +Z forward, resting on y=0. Node deck pivots on the trunnion axle at y=0.94, parallel to X, so the whole deck tips both ways. Clips: idle tips the deck 17 degrees each way and back through level over 4 s. Node TRS animation on named nodes only; no skinned rig, skeleton, collision or navigation data.
Use with an AI agent
Copy this prompt into your AI chat, then describe what you want to build with the asset.
Use the “Tilting platform on a trunnion axle (Animated Mechanisms Kit)” asset in my project. Model: https://cdn.3dassets.dev/assets/8549/v1/model.glb Asset page: https://3dassets.dev/assets/animated-mechanisms-kit-tilting-platform-e1cb4c09 Description: A 2.5 m by 1.9 m ribbed deck balanced on a trunnion axle between two painted bearing stools, with amber edge bands, floor kerbs and a lit control box. - Dimensions (X × Y × Z): 3.2 × 1.1 × 2.2 metres - Triangles: 368 - Animations: idle - Licence: CC0 1.0 Universal (https://creativecommons.org/publicdomain/zero/1.0/) - Loading: Three.js GLTFLoader; no additional decoders required.
Also available as JSON, Markdown, or via the MCP server.
Import manually
Choose your framework, then copy the code into your project to load the asset.
import { GLTFLoader } from 'three/addons/loaders/GLTFLoader.js'
import { AnimationMixer } from 'three'
let mixer
const loader = new GLTFLoader()
loader.load('https://cdn.3dassets.dev/assets/8549/v1/model.glb', (gltf) => {
scene.add(gltf.scene)
mixer = new AnimationMixer(gltf.scene)
mixer.clipAction(gltf.animations[0]).play()
})
// Call from your render loop; deltaSeconds is time since the previous frame.
function updateAssetAnimation(deltaSeconds) {
mixer?.update(deltaSeconds)
}Tilting platform on a trunnion axle (Animated Mechanisms Kit)
A 2.5 m by 1.9 m ribbed deck balanced on a trunnion axle between two painted bearing stools, with amber edge bands, floor kerbs and a lit control box.
